LIFTING & HANDLING TOOLS
1 TON CHAIN BLOCK (INDUSTRIAL)
CE/GS approval
Safe working load: 1Ton
Standard lift: 3m
Load chain fall: 1
Dynamic load: 15KN
Chain pull to lift full load: 250N
Load chain diameter: 6x18mm
Sealed roller bearing
Packing: color box
| Stock No. | Safe working load | Standard lift | Load chain fall | Dynamic load | Chain pull to lift full load | Load chain diameter | Qty./ carton |
| 62401 | 1 Ton | 3m | 1 | 15KN | 250N | 6x18mm | 1 |
2 TON CHAIN BLOCK (INDUSTRIAL)
CE/GS approval
Safe working load: 2Ton
Standard lift: 3m
Load chain fall: 1
Dynamic load: 30KN
Chain pull to lift full load: 335N
Load chain diameter: 8x24mm
Sealed roller bearing
Packing: color box
| Stock No. | Safe working load | Standard lift | Load chain fall | Dynamic load | Chain pull to lift full load | Load chain diameter | Qty./ carton |
| 62402 | 2 Ton | 3m | 1 | 30KN | 335N | 8x24mm | 1 |
3 TON CHAIN BLOCK (INDUSTRIAL)
CE/GS approval
Safe working load: 3Ton
Standard lift: 3m
Load chain fall: 2
Dynamic load: 45KN
Chain pull to lift full load: 265N
Load chain diameter: 7.1x21mm
Sealed roller bearing
Packing: color box
| Stock No. | Safe working load | Standard lift | Load chain fall | Dynamic load | Chain pull to lift full load | Load chain diameter | Qty./ carton |
| 62403 | 3 Ton | 3m | 2 | 45KN | 265N | 7.1x21mm | 1 |
5 TON CHAIN BLOCK (INDUSTRIAL)
CE/GS approval
Safe working load: 5Ton
Standard lift: 3m
Load chain fall: 2
Dynamic load: 75KN
Chain pull to lift full load: 360N
Load chain diameter: 9x27mm
Sealed roller bearing
Packing: color box
| Stock No. | Safe working load | Standard lift | Load chain fall | Dynamic load | Chain pull to lift full load | Load chain diameter | Qty./ carton |
| 62404 | 5 Ton | 3m | 2 | 75KN | 360N | 9x27mm | 1 |
ELECTRIC HOIST (INDUSTRIAL)
CE approval
Input power: 800W
Rated Voltage: 230V
Frequency:50Hz
Lifting weight:250Kgs(Single line) 500Kgs(Double line)
Lifting height:12m(Single line),6m(Double line)
Lifting speed:8m/min(Single line),4m/min(Double line)
Upper and lower limit device
Emergency stop switch
Thermal protection terminal
Packing: color box
| STOCK NO. | LIFTING WEIGHT | QTY./CARTON |
| 62491 | 250kg/500kg | 2 |
ELECTRIC HOIST (INDUSTRIAL)
CE approval
Input power: 1600W
Rated Voltage: 230V
Frequency:50Hz
Lifting weight:500Kgs(Single line) 999Kgs(Double line)
Lifting height:12m(Single line),6m(Double line)
Lifting speed:8m/min(Single line),4m/min(Double line)
Upper and lower limit device
Emergency stop switch
Thermal protection terminal
Packing: color box
| STOCK NO. | LIFTING WEIGHT | QTY./CARTON |
| 62492 | 500kg/999kg | 1 |
WEBBING SLING
• S.F.: 7:1
• The idea of lifting and moving heavy things
• Made from high tenacity 100% polyester webbing with
reinforced eye loops at both ends.
• High durability of scratch, friction, wear and tear
• More flexible and lighter, resistant to cutting and
abrasion
• Packing: color label with shrink
| STOCK NO. | SIZE | COLOR | QTY./CARTON |
| 62266 | 1Tx1M | Violet | 64 |
| 62267 | 1Tx2M | Violet | 32 |
| 62268 | 1Tx3M | Violet | 24 |
| 62269 | 2Tx1M | Green | 32 |
| 62270 | 2Tx2M | Green | 16 |
| 62271 | 2Tx3M | Green | 12 |
| 62272 | 2Tx4M | Green | 20 |
| 62273 | 2Tx5M | Green | 18 |
| 62274 | 2Tx6M | Green | 15 |
| 62275 | 3Tx2M | Yellow | 20 |
| 62276 | 3Tx3M | Yellow | 15 |
| 62277 | 3Tx4M | Yellow | 12 |
| 62278 | 3Tx5M | Yellow | 12 |
| 62279 | 3Tx6M | Yellow | 9 |
| 62280 | 4Tx3M | Grey | 10 |
| 62281 | 4Tx4M | Grey | 8 |
| 62282 | 4Tx5M | Grey | 8 |
| 62283 | 4Tx6M | Grey | 6 |
| 62284 | 5Tx3M | Red | 10 |
| 62285 | 5Tx4M | Red | 8 |
| 62286 | 5Tx5M | Red | 6 |
| 62287 | 5Tx6M | Red | 6 |
| 62288 | 5Tx8M | Red | 4 |
| 62289 | 6Tx4M | Brown | 5 |
| 62290 | 6Tx5M | Brown | 5 |
| 62291 | 6Tx6M | Brown | 4 |
| 62292 | 6Tx8M | Brown | 3 |
| 62295 | 8Tx6M | Blue | 3 |
| 62296 | 8Tx8M | Blue | 2 |
| 62298 | 10Tx6M | Orange | 2 |
| 62299 | 10Tx8M | Orange | 2 |
| 62300 | 10Tx10M | Orange | 1 |
