FEMALE STEEL INDUSTRIAL QUICK COUPLER G1/4″

• CE approval • Input power: 1500W / 2Hp • Rated Voltage: 220-240V • Air displacement: 188L/min • Max pump pressure: 8Bar(116psi) • Speed: 2850rpm • Noise: 92db • Belt driving system • Pump lubricated with oil • Features: • Suitable for workshop use • Thermal motor protection overload • Pressure regulator and pressure gauge • Wheels and transport handle • Packing: color box

STOCK NO.	SIZE	FREQUENCY	TANK	QTY./CARTON
73125	2Hp (1500W)	50/60HZ	24L	1
73126	2Hp (1500W)	50/60HZ	50L	1
95187	2Hp (1500W)	60HZ	24L	1



• CE approval • Type of feed: Suction • Air inlet: G1/4" male thread • Packing: by color box

STOCK NO.	STAINLESS STEEL NOZZLE	AIR CONSUMPTION	OPERATING AIR PRESSURE	SPRAY FAN PATTERN	PAINT CAPACITY	QTY./CARTON
73180	1.7mm	170L/min (6SCFM)	2.5-3.5Bar (35-50psi)	18-25cm	1000ml	10



• CE approval • Oversize: 53x49x23cm • Keep work space free from unwanted lengths of hose • Working pressure: 10bar / 150psi • Supplied with 15m+1.5m of PVC air line hose size 3/8"(9.5x15.8mm) • Hose connection 1/4" BSPT male thread • Max working pressure of hose: 300psi • Packing: color box

STOCK NO.	SIZE	QTY./ CATRON
73159	15M/50ft	1



• CE approved • Square drive: 1/2" • Operating air pressure: 6.2BAR (90PSI) • Air consumption: 110L/min • Air inlet: 1/4" • Air hose: 3/8" • Max torque: 69NM(50FT-LB) • Free speed: 160 rpm • Net weight: 1.18KGS • Packing: color box

STOCK NO.	SIZE	QTY./ CATRON
73315	1/2"	12
