GASOLINE CONCRETE VIBRATOR (INDUSTRIAL)

• Weight: 60kgs • Frequency:5600VPM • Centrifugal force:10.5kN • Compaction depth:20cm • Travel speed:40cm/s • Efficiency:450m²/hr • Plate size:50x36cm • Packing: carton box

STOCK NO.	ENGINE TYPE	POWER	WEIGHT
86101	Loncin model	4.8Kw(6.5HP)	60kgs
86102	Honda GX160	4.0Kw(5.5HP)	60kgs

• Weight: 125kgs • Frequency:4300VPM • Centrifugal force:25kN • Compaction depth:30cm • Travel speed:25cm/s • Efficiency:500m²/hr • Plate size:63x40cm • Packing: carton box

STOCK NO.	ENGINE TYPE	POWER	WEIGHT
86109	Loncin model	4.8Kw(6.5HP)	125kgs
86110	Honda GX160	4.0Kw(5.5HP)	125kgs

• Claw type fitting • Head length:580mm • Vibrating frequency:200Hz • Vibrating ampitude:1.2mm • Flexible hose length:6m • Packing: carton box

STOCK NO.	DIAMETER	FLEXIBLE HOSE LENGTH
86153	38mm	6m
86154	45mm	6m

• Engine power:9.6Kw(13HP) • Weight: 120kgs • Maximum cutting depth: 140mm • Cutting blade size: 300-450mm(12"-18") • Blade not included • Depth adjustment:handle rotation • Driving: Manual push • Water tank capacity:35L • Packing: carton box

STOCK NO.	ENGINE TYPE	POWER	CUTTING BLADE SIZE	WEIGHT	QTY./CARTON
86183	Loncin model	9.6Kw(13HP)	300-450mm, 12"-18"	120kgs	1
86184	Honda GX390	9.6Kw(13HP)	300-450mm, 12"-18"	120kgs	1
