MICROMETER TORQUE WRENCH WITH REVERSIBLE RATCHET (INDUSTRIAL)
• In accordance with ISO 6789
• Release accuracy tolerance ±3% of scale value
• The reversible with square drive and integrated lever-change reversible
ratchet function for controlled clockwise tightening
• Release signal when the value is reached
• High-quality steel tube, chrome-plated surface with scales
• Bi-color aluminum handle
• Packing: BMC with color sleeve
| STOCK NO. | SIZE | TORQUERANGE | LENGTH | QTY./CARTON |
| 19500 | 1/4″ | 1-5 N·m | 240mm | 12 |
| 19505 | 3/8″ | 5-25 N·m | 240mm | 12 |
| 19510 | 1/2″ | 10-50 N·m | 275mm | 12 |
| 19513 | 1/2″ | 400-200 N·m | 503mm | 6 |
| 19522 | 3/4″ | 200-1000 N·m | 1225mm | 4 |
| 19525 | 1″ | 100-500 N·m | 945mm | 4 |
| 19527 | 1″ | 200-1000 N·m | 1225mm | 4 |
| 19531 | 9x12mm | 10-50 N·m | 260mm | 12 |
| 19660 | 1/4″ | 1-6 N·m/8.9-53.1 in.lbs. | 210mm | 6 |
| 19661 | 1/4″ | 5-25 N·m/44.3-221.4 in.lbs. | 240mm | 6 |
| 19663 | 3/8″ | 10-60 N·m/88.6-531.4 in.lbs. | 310mm | 6 |
| 19664 | 3/8″ | 20-120 N·m/14.8-88.6 ft.lbs. | 420mm | 6 |
| 19666 | 1/2″ | 20-120 N·m/14.8-88.6 ft.lbs. | 420mm | 6 |
| 19667 | 1/2″ | 40-220 N·m/29.5-162.4 ft.lbs. | 510mm | 6 |
| 19668 | 1/2″ | 60-330 N·m/44.3-243.6 ft.lbs. | 560mm | 6 |
| 19669 | 3/4″ | 100-600 N·m/73.8-442.8 ft.lbs. | 1010mm | 2 |
| 19670 | 3/4″ | 160-800 N·m/118.1-590.4 ft.lbs. | 1210mm | 2 |
| 19671 | 1″ | 240-1200 N·m/177.1-885.7 ft.lbs. | 1825mm | 2 |
| 19672 | 1″ | 300-1500 N·m/221.4-1107.1 ft.lbs. | 1825mm | 2 |
