20V LI-ION CORDLESS IMPACT DRILL
• CE approval
• Li-Ion battery
• Keyless chuck
• Spindle automatic locking
• Step speed selection
• Electronic speed adjustment
• Reverse function
• Variable torque
• 3 modes (screwdriving/drilling/impact drilling)
• LED light
• LED battery power indicator
• Belt hook
• Includes:
2pcs 2.0Ah battery pack
1pc battery charger: 100-240VAC 50/60Hz,
Europlug, 1hr fast charging
HSS drill bits: 3,4,5,6mm
Masonry drill bits: 5,6,8mm
6pcs bits: 5mm,6.5mm, PH1, PH2, PZ1, PZ2
1pcs magnetic nut socket: 1/4″x60mm
• Packing: BMC+color sleeve
| Rated voltage | 20V |
| No-load speed | 0-400/0-1400min-1 |
| Impact rate | 6000/22500 bpm |
| Chuck capacity | 1.5-10mm |
| Max. torque | 35 N·m |
| Clutch | 15+1 setting |
| Max. drilling capacity in wood | 25mm |
| Max. drilling capacity in steel | 10mm |
| Max. drilling capacity in concrete | 10mm |
| QTY./CARTON | 5 |
| STOCK NO. | 87203 |
SKU:
87203
Category: 20V LITHIUM-ION PLATFORM
Attachment
87203-Parts List
DownloadRelated products
20V LI-ION CORDLESS DRILL
• CE approval
• Li-Ion battery
• Keyless chuck
• Spindle automatic locking
• Step speed selection
• Electronic speed adjustment
• Reverse function
• Variable torque
• 2 modes (screwdriving / drilling)
• LED light
• LED battery power indicator
• Belt hook
• Includes:
2pcs 2.0Ah battery packs
1pc battery charger: 220-240VAC 50/60Hz,
Europlug, 1hr fast charging
• Packing: canvas bag with color box
| Voltage | 20V |
| No-load speed | 0-400/0-1500min-1 |
| Chuck capacity | 0.8-10mm (3/8”) |
| Max. torque | 35 N.m (310in.lbs.) |
| Clutch | 21+1 setting |
| Max. drilling capacity in wood | 25mm (1”) |
| Max. drilling capacity in steel | 10mm (3/8”) |
| QTY./CARTON | 6 |
| STOCK NO. | 87212 |
20V LI-ION CORDLESS IMPACT DRILL
• CE approval
• Li-Ion battery
• Metal keyless chuck
• Spindle automatic locking
• Step speed selection
• Electronic speed adjustment
• Reverse function
• Variable torque
• 3 modes (screwdriving / drilling / impact drilling)
• LED light
• LED battery power indicator
• Belt hook
• Includes:
2pcs 2.0Ah battery packs
1pc battery charger: 220-240VAC 50/60Hz,
Europlug, 1hr fast charging
HSS drill bits: 3,4,5,6mm
Masonry drill bits: 5,6,8mm
6pcs bits: 5mm,6mm,PH1,PH2,PZ1,PZ2
1pcs magnetic nut socket: 1/4"x60mm
• Packing: BMC+color sleeve
| Voltage | 20V |
| No-load speed | 0-450/0-1700min-1 |
| Impact rate | 7200/27200 bpm |
| Chuck capacity | 2.0-13mm (1/2”) |
| Max. torque | 55 N.m (487in.lbs.) |
| Clutch | 21+1+1 setting |
| Max. drilling capacity in wood | 35mm (1-3/8”) |
| Max. drilling capacity in steel | 13mm (1/2”) |
| Max. drilling capacity in concrete | 13mm (1/2”) |
| QTY./CARTON | 5 |
| STOCK NO. | 87215 |
20V LI-ION BRUSHLESS CORDLESS IMPACT DRIVER (INDUSTRIAL)
• Brushless motor
• CE approval
• Li-Ion battery
• 1/4" hexagonal tool holder
• Electronic speed adjustment
• Variable torque
• Reverse function
• Integrated LED light
• LED battery power indicator
• Belt hook
• Includes:
2pcs 2.0Ah battery packs
1pc battery charger: 220-240VAC 50/60Hz,
Europlug, 1hr fast charging
• Packing: canvas bag with color box
| Voltage | 20V |
| No-load speed | 0-2900min-1 |
| Impact rate | 0-3000 ipm |
| Max. torque | 200 N.m (148ft.lbs.) |
| Chuck type | 1/4" Hex |
| QTY./CARTON | 4 |
| STOCK NO. | 87256 |
20V LI-ION BRUSHLESS CORDLESS RECIPROCATING SAW (INDUSTRIAL)
• Brushless motor
• CE approval
• Stroke rate regulation
• Lock-off function
• Saw blade quick changing system
• Integrated LED light
• Soft grip
• Battery/charger not included
• Packing: color box
| Battery pack voltage | 20V |
| No-load speed | 0-2500min-1 |
| Stroke length | 28mm (1-1/16”) |
| Cutting capacity in wood | 180mm (7”) |
| Cutting capacity in metal | 8mm (1/4”) |
| QTY./CARTON | 6 |
| STOCK NO. | 87280 |
20V LI-ION BRUSHLESS CORDLESS CIRCULAR SAW (INDUSTRIAL)
• Brushless motor
• CE approval
• Soft start
• Spindle lock function
• Locking switch with auxiliary handle
• Aluminium base plate
• Integrated LED light
• Battery/charger not included
• Packing: color box
| Battery pack voltage | 20V |
| No-load speed | 3800min-1 |
| Circular saw blade | Ø185mm (7-1/4”) |
| Bore | Ø20mm |
| Max. cutting depth at 90° | 62mm (2-7/16") |
| Max. cutting depth at 45° | 43mm (1-3/4") |
| QTY./CARTON | 4 |
| STOCK NO. | 87282 |
