20V LI-ION CORDLESS LASER LEVEL
• CE approval
• Outdoor pulse function
• 12 lines
• Accessories
1pc black nylon stand, 90mm lift adjustable; front and rear 55mm adjustable gap;
1/4″ and 5/8″ copper threaded holes on bottom; strong magnet on side
1pc sheet metal clip
• Packing: BMC with color box
| Rated voltage | 20V |
| Input power | 20W |
| Wavelength | 520nm Green light |
| Beam Accuracy | H/V Line ±3mm/10m |
| Laser intensity | Class II, <1mw |
| Self leveling | 0-4° |
| Expanded Angle | H&V 360° |
| Max. working distance | 30m (without detector) |
| Running time | 3C ≥ 15 hours (20V 87472) |
| Working environment temperature | -10°C–+50°C |
| Storage ambient temperature | -20°C–+70°C |
| Function mode | 1C, 2C, 3C |
| QTY./CARTON | 6 |
| STOCK NO. | 87324 |
SKU:
87324
Category: 20V LITHIUM-ION PLATFORM
Attachment
87324-Instruction Manual
DownloadRelated products
20V LI-ION CORDLESS DRILL
• CE approval
• Li-Ion battery
• Keyless chuck
• Spindle automatic locking
• Step speed selection
• Electronic speed adjustment
• Reverse function
• Variable torque
• 2 modes (screwdriving / drilling)
• LED light
• LED battery power indicator
• Belt hook
• Includes:
2pcs 2.0Ah battery packs
1pc battery charger: 220-240VAC 50/60Hz,
Europlug, 1hr fast charging
• Packing: canvas bag with color box
| Voltage | 20V |
| No-load speed | 0-400/0-1500min-1 |
| Chuck capacity | 0.8-10mm (3/8”) |
| Max. torque | 35 N.m (310in.lbs.) |
| Clutch | 21+1 setting |
| Max. drilling capacity in wood | 25mm (1”) |
| Max. drilling capacity in steel | 10mm (3/8”) |
| QTY./CARTON | 6 |
| STOCK NO. | 87212 |
20V LI-ION BRUSHLESS CORDLESS DRILL (INDUSTRIAL)
• Brushless motor
• CE approval
• Li-Ion battery
• Metal keyless chuck
• Spindle automatic locking
• Step speed selection
• Electronic speed adjustment
• Reverse function
• Variable torque
• 2 modes (screwdriving / drilling)
• LED light
• LED battery power indicator
• Belt hook
• Includes:
1pc 2.0Ah battery packs
1pc battery charger: 220-240VAC 50/60Hz,
Europlug, 1hr fast charging
• Packing: color box
| Voltage | 20V |
| No-load speed | 0-500/0-2000min-1 |
| Chuck capacity | 2-13mm (1/2”) |
| Max. torque | 58 N.m (513in.lbs.) |
| Clutch | 21+1 setting |
| Max. drilling capacity in wood | 38mm (1-1/2”) |
| Max. drilling capacity in steel | 13mm (1/2”) |
| QTY./CARTON | 6 |
| STOCK NO. | 87252 |
20V LI-ION BRUSHLESS CORDLESS IMPACT DRILL (INDUSTRIAL)
• Brushless motor
• CE approval
• Li-Ion battery
• Metal keyless chuck
• Spindle automatic locking
• Step speed selection
• Electronic speed adjustment
• Reverse function
• Variable torque
• 3 modes (screwdriving / drilling / impact drilling)
• LED light
• LED battery power indicator
• Belt hook
• Includes:
2pcs 2.0Ah battery packs
1pc battery charger: 220-240VAC 50/60Hz,
Europlug, 1hr fast charging
HSS drill bits: 3,4,5,6mm
Masonry drill bits: 5,6,8mm
6pcs bits: 5mm,6mm,PH1,PH2,PZ1,PZ2
1pcs magnetic nut socket: 1/4"x60mm
• Packing: BMC+color sleeve
| Voltage | 20V |
| No-load speed | 0-500/0-2000min-1 |
| Impact rate | 8000/32000 bpm |
| Chuck capacity | 2-13mm (1/2”) |
| Max. torque | 58 N.m (513in.lbs.) |
| Clutch | 21+1+1 setting |
| Max. drilling capacity in wood | 38mm (1-1/2”) |
| Max. drilling capacity in steel | 13mm (1/2”) |
| Max. drilling capacity in concrete | 13mm (1/2”) |
| QTY./CARTON | 4 |
| STOCK NO. | 87254 |
20V LI-ION BRUSHLESS CORDLESS IMPACT DRIVER (INDUSTRIAL)
• Brushless motor
• CE approval
• Li-Ion battery
• 1/4" hexagonal tool holder
• Electronic speed adjustment
• Variable torque
• Reverse function
• Integrated LED light
• LED battery power indicator
• Belt hook
• Includes:
2pcs 2.0Ah battery packs
1pc battery charger: 220-240VAC 50/60Hz,
Europlug, 1hr fast charging
• Packing: canvas bag with color box
| Voltage | 20V |
| No-load speed | 0-2900min-1 |
| Impact rate | 0-3000 ipm |
| Max. torque | 200 N.m (148ft.lbs.) |
| Chuck type | 1/4" Hex |
| QTY./CARTON | 4 |
| STOCK NO. | 87256 |
20V LI-ION BRUSHLESS CORDLESS ANGLE GRINDER (INDUSTRIAL)
• Brushless motor
• CE approval
• Soft start
• Restart protection
• Safety clutch
• Quick adjustable protective casing
• Soft grip
• Battery/charger not included
• With 1pc side handle and 1pc wrench
• Packing: color box
| Voltage | 20V |
| Diameter of wheel | 125mm / 5" |
| No-load speed | 10000min-1 |
| Spindle thread | M14 |
| QTY./CARTON | 4 |
| STOCK NO. | 87278 |
